OIDD
Operation Information Display Device - OIDD
Overview

The System is saving and expressing game information among commercial arcade game consols offering game services and delivering the information to institutions(Game Rating And Administration Committee and investigative agencies) to read it.

Characteristics
  • Through interface with game device and bill reader the info about game management is delivered and saved and control signals occurs in real time.
  • All th info during game is displayed in LCD screen on OIDD device available for watching by gamer.
Spec.
Item OIDD Specifications
Output Power 1.15W
Port • Power 4 pins
• 5 pins (Coin injector)
• 10 pins (Gift injector)
• 5 pins (UART)
• USB
• 5 pins (Gift discharger)
• 10 pins (Bill reader)
Item Description
Dimensions (mm, W*H*D) 147 x 87 x 28.7
Weight 180g
Operating Temperature +5 ~ +50℃
Cooling Natural Convection
